OPK Speed Boat – Glass Slide System

Door width     –         Up to 1500mm

Door Height   –         up to 1000mm

Glass  Thickness   –    4 – 6mm

Door Weight       –      20Kg

Height Adjustment  –   +3mm

Soft close            –         Yes

Single Top Track   –   Per Door Width X 2

This looks like a list of components included in a sliding door hardware kit, along with some of the system’s advantages. Here’s a breakdown:

What’s Included: This section lists the individual parts you’ll receive in the kit:

• Top Single Track: This is the rail at the top of the door frame that the door hangs from. The length you get is twice the width of the door you select.
• Top Bearing Wheels: These wheels attach to the top of the door and run along the track, allowing the door to slide open and closed. You get two wheels per door.
• Soft Close: This mechanism gently slows the door as it’s being closed, preventing it from slamming. You get one soft close mechanism per door.
• Base Guide Clip: This clip is installed at the bottom of the door to keep it aligned and prevent it from swinging outwards. You get one clip per door.

Advantages at a Glance: This section highlights the benefits of this sliding door system:

• Versatility: The system is adaptable to different construction types (InSide, MixSide) and can be used with both wooden and glass doors.
• Door Compatibility: It works with wooden doors that are 16mm thick or more, and glass doors that are 4-6mm thick. It also includes a special glass holder with a safety feature.
• Ease of Installation: The system is designed for simple installation and allows for height adjustments to ensure a perfect fit.
• Quality and Performance: The system uses a durable aluminum track and high-quality fittings with plastic rollers, enabling smooth and quiet operation for doors weighing up to 20kg.
• Integrated Damping: The soft close mechanism provides damping on both sides of the door’s movement, and it’s discreetly built into the track.
