Slide System, Solid Wood and Profiled Wood or Glass, Ceiling Mounted, TW14TS
Double system , Space + 2 Telescopic system will allow user to slide both sets of door Panels into a space be it a pocket space or Exposed .
OPK Spaceship is a sliding door system in the construction sector. can be used to go within a pocket of exposed System
Its technically advanced system makes OPK Spaceship suitable for ceiling mounted applications.
High-quality carriages with ball-bearing plastic rollers move in elegant aluminium profiles EV1, which guarantee a light, wear-resistant and quiet running. Moving parts are protected from dirt by a self-cleaning construction. The assembly is simple, fast and efficient.
Whats Included
Please note ! This is system only, No door Panel included in this Purchase.
1. Top Single Track – Dimension Selected x 2
2. 2 x Floor Mounted Bottom Bearing guide Wheel , 2 x Telescopic Door Connection Fitting
3. 4 x Wheel sets
3. Soft close – Two way for 4 Doors
4. U channel base Rail for under Door , track Dimension Divided x 2 ( approx Door Width )
Advantages at a Glance
- The advantages at a glance
- Wooden doors
- Easy, fast installation, height adjustment +/- 3 mm
- Door weight up to 80 kg
- Door widths from 580 mm
- Both sides damping
- Veneering of the track possible
- Ball-bearing floor guide
